Carestream HPX Pro
The HPX-PRO CR system is built for high image quality, improved productivity and extreme portability. This next-generation system is a lightweight, portable CR imaging solution that is quick to deploy and rapidly produces high-quality images utilizing a new single-pass scan/erase protocol.
Overview
The HPX-PRO's software incorporates a new user interface designed to get you set-up and imaging fast, with batch mode capability to keep in pace with extreme process conditions like pipeline imaging. The new software tools also provide quick image analysis and customised reporting for generating unique customer reports in seconds. From hardware to software, to deep in the field and instant image sharing, the HPX-PRO is a complete system, designed to improve productivity.
For further information on pricing and availability please email our dedicated Carestream Industrex team.
Features
- Can be hand held with ease
- Can be operated off main power, so you can work where you need to without power limitations
- INDUSTREX Software with a new simplified user interface
- INDUSTREX Software Custom reporting
Specification
| Standard Specification | |
|---|---|
| Feed Mechanism | Internal horizontal roller pairs |
| Connectivity | Ethernet |
| Network | DICOM and DICONDE compliant |
| Air Flow | Filtered, positive air flow in scanner for temperature control |
| Scanning Optics | Located above imaging area eliminating gravity driven particulates |
| Erase | LED erase lamps for high efficiency and low power consumption |
| Maintenance | User serviceable wear parts |
| Calibration | Fully factory calibrated and ready to operate |
| Scan Resolution | 25micron, 50micron & 100micron |
| Plate Sizes | Maximum 6inch width x maximum 96inch length |
| Software | INDUSTREX (installed and tested prior to shipping) Windows 7 Ultimate 64 bit |
| Filter | Carestream’s EDGE image filter offers users a choice of display filters while never modifying the original source image. Image can be sharpened or enhanced with gray scale equalization. |
| Monitor | Laptop, 3MP (color) or 5MP (monochrome) |
| Chassis | Rigid aluminum construction with vibration damping feet |
| Power | 100-240VAC (Automatic Level Sensing) |
| Battery | 24volt standard tool battery |
| Battery Life | 4 hour standby/45 minutes active scanning and erasing per battery |
| Warranty | 1 year parts and labor |
| Installation | Ships complete and can be quickly and easily installed on-site by customer |
| Dimensions | 16inches (41cm) x 13inches (33cm) x 12inches (31cm) |
| Weight | 35 lbs (16 kg) |
Downloads
Brochure & Specification
| Type | Title | Date | Size | |
|---|---|---|---|---|
 |
Carestream HPX Pro Brochure | 09/23 | Download | 0.91 MB |
