DAC Blocks
For setting DAC curves in shear and compression wave inspections.
Overview
Block Type:
DAC Calibration Block
Description:
200mm x 50mm x 75mm block with 4 x 3mm side drilled holes (SDH) at specified depths.
Variants:
- Alternate material choices available, define the material on RFQ
- Nickel plating and black anodising available on RFQ
- Side drilled hole diameters can be changed on RFQ
- A1Depth of side drilled holes can be modified on RFQ.
CALBLK-DAC-102
Specification
| Product Code | Block Type | Variant |
|---|---|---|
| CALBLK-DAC-101 | DAC Block with 4 x 3mm SDHs | SDH depths 20%, 40%, 60% and 80% of the block thickness |
| CALBLK-DAC-102 | DAC Block with 4 x 3mm SDHs | SDH depths 10%, 33%, 66% and 90% of the block thickness |
Alternate material choices available, define the material on RFQ
Nickel plating and black anodising available on RFQ
Side drilled hole diameters can be changed on RFQ
A1Depth of side drilled holes can be modified on RFQ.
